Secure Gateways for enterprise

• Unified access policy: firewall, application control
• Policy layers and sub-policies
• Acceleration of domain, dynamic and time objects
• Multicore VPN and VPN acceleration
• Smart Accel 30% performance improvement*

N/A*

• Single Power Supply rating AC: 2 x 150W
• Power input: 100 to 240VAC (50-60Hz)
• Power consumption avg/max: 93.6W
• Maximum thermal output AC 319.3BTU/h

• Enclosure: 1RU
• Dimensions: (WxDxH): 16.93 x 11.8 x 1.74 in. (430 x 300 x 44.2 mm)
• Weight: (gross; Kg): 6.76

UL/c-UL 62368-1 , IEC 62368-1 CB / EMC, EMI EN55024, EN55032 Class B, VCCI, AS, NZS CISPR 32, IC ICES 03, FCC: Part 15 Class B / RoHS, REACH, WEEE

• Unified access policy: firewall, application control
• Policy layers and sub-policies
• Acceleration of domain, dynamic and time objects
• Multicore VPN and VPN acceleration
• Smart Accel 30% performance improvement*

N/A*

• Single Power Supply rating AC: 2 x 150W
• Power input: 100 to 240VAC (50-60Hz)
• Power consumption avg/max: 93.6W
• Maximum thermal output AC 319.3BTU/h

• Enclosure: 1RU
• Dimensions: (WxDxH): 16.93 x 11.8 x 1.74 in. (430 x 300 x 44.2 mm)
• Weight: (gross; Kg): 6.76

UL/c-UL 62368-1 , IEC 62368-1 CB / EMC, EMI EN55024, EN55032 Class B, VCCI, AS, NZS CISPR 32, IC ICES 03, FCC: Part 15 Class B / RoHS, REACH, WEEE

• Network security snapshot: view connected devices and threats
• Real-time security alerts: attacks and unauthorized devices
• On-the-spot threat mitigation: quickly block infected devices
• Network statistic reports and charts
• Manage multiple gateways

N/A*

• Single Power Supply rating AC: 150W
• Power input: 100 to 240VAC (50-60Hz)
• Power consumption avg/max: 93.6W
• Maximum thermal output AC 319.3BTU/h

• Enclosure: 1RU
• Dimensions: (WxDxH): 16.93 x 11.8 x 1.74 in. (430 x 300 x 44.2 mm)
• Weight: (gross; Kg): 6.76

UL/c-UL 62368-1 , IEC 62368-1 CB / EMC, EMI EN55024, EN55032 Class B, VCCI, AS, NZS CISPR 32, IC ICES 03, FCC: Part 15 Class B / RoHS, REACH, WEEE

• Network security snapshot: view connected devices and threats
• Real-time security alerts: attacks and unauthorized devices
• On-the-spot threat mitigation: quickly block infected devices
• Network statistic reports and charts
• Manage multiple gateways

N/A*

• Single Power Supply rating AC: 150W
• Power input: 100 to 240VAC (50-60Hz)
• Power consumption avg/max: 71.6W
• Maximum thermal output AC 244.31BTU/h

• Enclosure: 1RU
• Dimensions: (WxDxH): 16.93 x 11.8 x 1.74 in. (430 x 300 x 44.2 mm)
• Weight: (gross; Kg): 6.17

UL/c-UL 62368-1 , IEC 62368-1 CB / EMC, EMI EN55024, EN55032 Class B, VCCI, AS, NZS CISPR 32, IC ICES 03, FCC: Part 15 Class B / RoHS, REACH, WEEE

• Network security snapshot: view connected devices and threats
• Real-time security alerts: attacks and unauthorized devices
• On-the-spot threat mitigation: quickly block infected devices
• Network statistic reports and charts
• Manage multiple gateways

N/A*

• Single Power Supply rating AC: 40W (Wired) / 60W (Wi-Fi)
• Power input: 100 to 240VAC (50-60Hz)
• Power consumption avg/max: 26.01W (Wired) / 35.5W (Wi-Fi)
• Maximum thermal output AC 88.75 (Wired) / 127.14BTU/h (Wi-Fi)

• Enclosure: Desktop
• Dimensions: (WxDxH): 8.3 x 6.7 x 1.7 in. (210 x 170 x 42 mm)
• Weight: (gross; Kg): 0.87

CB 62368-1, CE, CE 62368-1, UL 62638-1, CB 60950-1, FCC IC Class B, CE LVD, VCCI, AS/NZS RCM EMC, RoHS, REACH, WEEE

• Network security snapshot: view connected devices and threats
• Real-time security alerts: attacks and unauthorized devices
• On-the-spot threat mitigation: quickly block infected devices
• Network statistic reports and charts
• Manage multiple gateways

N/A*

• Single Power Supply rating AC: 40W (Wired) / 60W (Wi-Fi)
• Power input: 100 to 240VAC (50-60Hz)
• Power consumption avg/max: 26.01W (Wired) / 35.5W (Wi-Fi)
• Maximum thermal output AC 88.75 (Wired) / 127.14BTU/h (Wi-Fi)

• Enclosure: Desktop
• Dimensions: (WxDxH): 8.3 x 6.7 x 1.7 in. (210 x 170 x 42 mm)
• Weight: (gross; Kg): 0.87

CB 62368-1, CE, CE 62368-1, UL 62638-1, CB 60950-1, FCC IC Class B, CE LVD, VCCI, AS/NZS RCM EMC, RoHS, REACH, WEEE

• Network security snapshot: view connected devices and threats
• Real-time security alerts: attacks and unauthorized devices
• On-the-spot threat mitigation: quickly block infected devices
• Network statistic reports and charts
• Manage multiple gateways

N/A*

• Single Power Supply rating AC: 40W (Wired) / 60W (Wi-Fi)
• Power input: 100 to 240VAC (50-60Hz)
• Power consumption avg/max: 26.01W (Wired) / 35.5W (Wi-Fi)
• Maximum thermal output AC 88.75 (Wired) / 127.14BTU/h (Wi-Fi)

• Enclosure: Desktop
• Dimensions: (WxDxH): 8.3 x 6.7 x 1.7 in. (210 x 170 x 42 mm)
• Weight: (gross; Kg): 0.87

CB 62368-1, CE, CE 62368-1, UL 62638-1, CB 60950-1, FCC IC Class B, CE LVD, VCCI, AS/NZS RCM EMC, RoHS, REACH, WEEE

• Network security snapshot: view connected devices and threats
• Real-time security alerts: attacks and unauthorized devices
• On-the-spot threat mitigation: quickly block infected devices
• Network statistic reports and charts
• Manage multiple gateways

N/A*

• Single Power Supply rating AC: 40W (Wired) / 60W (Wi-Fi)
• Power input: 100 to 240VAC (50-60Hz)
• Power consumption avg/max: 26.01W (Wired) / 35.5W (Wi-Fi)
• Maximum thermal output AC 88.75 (Wired) / 127.14BTU/h (Wi-Fi)

• Enclosure: Desktop
• Dimensions: (WxDxH): 8.3 x 6.7 x 1.7 in. (210 x 170 x 42 mm)
• Weight: (gross; Kg): 0.87

CB 62368-1, CE, CE 62368-1, UL 62638-1, CB 60950-1, FCC IC Class B, CE LVD, VCCI, AS/NZS RCM EMC, RoHS, REACH, WEEE

• Unified access policy: firewall, application control
• Policy layers and sub-policies
• Acceleration of domain, dynamic and time objects
• Multicore VPN and VPN acceleration
• Smart Accel 30% performance improvement*

N/A*

• Single Power Supply rating AC: 120W
• Power input: 100 to 240VAC (50-60Hz)
• Power consumption avg/max: 29.5W
• Maximum thermal output AC 100.6BTU/h

• Enclosure: Desktop, wall mount, DIN rail
• Dimensions: (WxDxH): 150 x 170 x 42 mm, 5.9 x 6.7 x 1.7 in
• Weight: (gross; Kg): 1.36

CB IEC, UL, CE LVD - IEC 62368-1, UL/c 62368-1, CE LVD, EN62368-1, ASNZ 62368-1, CE, UKCA, FCC, IC , VCCI, AS_NZS ACMA, RoHS, REACH, WEEE, POP, TSCA

• Unified access policy: firewall, application control
• Policy layers and sub-policies
• Acceleration of domain, dynamic and time objects
• Multicore VPN and VPN acceleration
• Smart Accel 30% performance improvement*

N/A*

• Single Power Supply rating AC: 2 x 150W
• Power input: 100 to 240VAC (50-60Hz)
• Power consumption avg/max: 93.6W
• Maximum thermal output AC 319.3BTU/h

• Enclosure: 1RU
• Dimensions: (WxDxH): 16.93 x 11.8 x 1.74 in. (430 x 300 x 44.2 mm)
• Weight: (gross; Kg): 6.76

UL/c-UL 62368-1 , IEC 62368-1 CB / EMC, EMI EN55024, EN55032 Class B, VCCI, AS, NZS CISPR 32, IC ICES 03, FCC: Part 15 Class B / RoHS, REACH, WEEE

• 1 CPU, 20 physical cores, 40 virtual (total)
• Storage: BASE x 1 SSD 960GB NVMe, PLUS x 2 SSD 960GB NVMe
• Power: BASE x 1 External AC PSU, PLUS x 2 External AC PSUs
• 32 (64 in PLUS model) to 128 GB memory options

• 8 x 1/10GBASE-F SFP+ port card
• 4 x 10/25GBASE-F SFP28 port card
• 2 x 40/100GBASE-F QSFP28 port card

• Single Power Supply rating AC: 450W
• Power input: 100 to 240VAC (47-63Hz), -40~-70VDC
• Power consumption avg/max: 233.5W/389.3W
• Maximum thermal output AC 1328.3BTU/h

• Enclosure: 1RU
• Dimensions: (WxDxH): 17.2 x 20 x 1.73 in.(438 x 508 x 44mm)
• Weight: (gross; Kg): 16.9

• Safety: CB IEC 62368-1, CE LVD EN62368-1, UL62368-1, ASNZS 62368.1
• Emissions: CE, FCC IC, VCCI, ASNZS ACMA
• Environmental: ROHS, REACH, WEEE, ISO14001

• CPU: 16 physical cores, total of 32 logical cores
• Storage: BASE x 1 SSD 960GB NVMe, PLUS x 2 SSD 960GB NVMe
• Power: BASE x 1 External AC PSU, PLUS x 2 External AC PSUs
• 32 (64 in PLUS model) to 128 GB memory options
• Lights-Out-Management card – optional (included in Plus package)

• 8 x 1/10GBASE-F SFP+ port card
• 4 x 10/25GBASE-F SFP28 port card
• 2 x 40/100GBASE-F QSFP28 port card

• Single Power Supply rating AC: 450W
• Power input: 100 to 240VAC (47-63Hz)
• Power consumption avg/max: 224.5W/374.3W
• Maximum thermal output AC 1277.1BTU/h

• Enclosure: 1RU
• Dimensions: (WxDxH): 17.2 x 20 x 1.73 in.(438 x 508 x 44mm)
• Weight: (gross; Kg): 16.9

• Safety: CB IEC 62368-1, CE LVD EN62368-1, UL62368-1, ASNZS 62368.1
• Emissions: CE, FCC IC, VCCI, ASNZS ACMA
• Environmental: ROHS, REACH, WEEE, ISO14001

• 1 CPU, 14 physical cores, 20 virtual (total)
• Storage: 1 SSD 960GB SATA
• Power: BASE x 1 External AC PSU, PLUS x 2 External AC PSUs
• 16 to 64 GB memory options
• Lights-Out-Management card – optional (included in Plus package

• 8 x 1/10GBASE-F SFP+ port card
• 4 x 10/25GBASE-F SFP28 port card
• 2 x 40/100GBASE-F QSFP28 port card

• Single Power Supply rating AC: 320W
• Power input: 100 to 240VAC (47-63Hz)
• Power consumption avg/max: 105.1W/175.3W
• Maximum thermal output AC: 597.7BTU/s

• Enclosure: 1RU
• Dimensions: (WxDxH): 17.2 x 20 x 1.73 in.(438 x 508 x 44mm)
• Weight: (gross; Kg): 15.97

• Safety: CB IEC 62368-1, CE LVD EN62368-1, UL62368-1, ASNZS 62368.1
• Emissions: CE, FCC IC, VCCI, ASNZS ACMA
• Environmental: ROHS, REACH, WEEE, ISO14001

• CPU: 10 physical cores, total of 16 logical cores
• Storage: 1 SSD 480GB SATA
• Power: BASE x 1 External AC PSU, PLUS x 2 External AC PSUs
• 16 to 64 GB memory options
• Lights-Out-Management card – optional (included in Plus package)

• 8 x 1/10GBASE-F SFP+ port card
• 4 x 10/25GBASE-F SFP28 port card

• Single Power Supply rating AC: 320W
• Power input: 100 to 240VAC (47-63Hz)
• Power consumption avg/max: 96W/160W
• Maximum thermal output AC: 545.6BTU/s

• Enclosure: 1RU
• Dimensions: (WxDxH): 17.2 x 20 x 1.73 in.(438 x 508 x 44mm)
• Weight: (gross; Kg): 15.97

• Safety: CB IEC 62368-1, CE LVD EN62368-1, UL62368-1, ASNZS 62368.1
• Emissions: CE, FCC IC, VCCI, ASNZS ACMA
• Environmental: ROHS, REACH, WEEE, ISO14001

• CPU: 4 physical cores, total of 8 logical cores
• Storage: 1 SSD 480GB SATA
• 2x Internal AC power supply
• 16 to 64 GB memory options
• Lights-Out-Management card – optional (included in Plus package)

• 8 x 1/10GBASE-F SFP+ port card
• 4 x 10/25GBASE-F SFP28 port card

• Single Power Supply rating AC: 200W
• Power input: 100 to 240VAC (47-63Hz)
• Power consumption avg/max: 84.4W/140.8W
• Maximum thermal output AC: 480.1BTU/s

• Enclosure: 1RU
• Dimensions: (WxDxH): 17.2 x 20 x 1.73 in.(438 x 508 x 44mm)
• Weight: (gross; Kg): 14.8

• Safety: CB IEC 62368-1, CE LVD EN62368-1, UL62368-1, ASNZS 62368.1
• Emissions: CE, FCC IC, VCCI, ASNZS ACMA
• Environmental: ROHS, REACH, WEEE, ISO14001

• 1 CPU, 4 physical cores, 8 virtual
• Storage: 1 SSD 480GB SATA
• 2x Internal AC power supply
• 16 to 64 GB memory options
• Lights-Out-Management card – optional (included in Plus package)

• 8 x 1/10GBASE-F SFP+ port card
• 4 x 10/25GBASE-F SFP28 port card

• Single Power Supply rating AC: 200W
• Power input: 100 to 240VAC (47-63Hz)
• Power consumption avg/max: 84.4W /140.8W
• Maximum thermal output AC: 480.1BTU/s

• Enclosure: 1RU
• Dimensions: (WxDxH): 17.2 x 20 x 1.73 in.(438 x 508 x 44mm)
• Weight: (gross; Kg): 14.8

• Safety: CB IEC 62368-1, CE LVD EN62368-1, UL62368-1, ASNZS 62368.1
• Emissions: CE, FCC IC, VCCI, ASNZS ACMA
• Environmental: ROHS, REACH, WEEE, ISO14001

• CPU: 64 physical cores, total of 128 logical cores
• Storage: BASE x 1 SSD 960GB NVMe, PLUS x 2 SSD 960GB NVMe
• 2x AC power supplies
• 128, 192 and 256 GB memory options
• Lights-Out-Management card (included in Plus package)

• 8 x 1/10GBASE-F SFP+ port card, up to 56 ports
• 4 x 10/25GBASE-F SFP28 port card, up to 30 ports
• 2 x 40/100GBASE-F QSFP28 port card, up to 14 ports

• Single Power Supply rating AC: 1300W
• Power input: 100 to 240VAC (47-63Hz)
• Power consumption 110VAC avg/max: 600W/999W
• Maximum thermal output AC: 3408.7 BTU/hr.

• Enclosure: 2RU
• Dimensions (WxDxH): 17.25 x 24 x 3.5 in. (442 x 610 x 88mm)
• Weight: 42.1 lbs. (19.1 kg)

• Safety: CB IEC 62368-1, CE LVD EN62368-1, UL62368-1, ASNZS 62368.1
• Emissions: CE, FCC IC, VCCI, ASNZS ACMA
• Environmental: ROHS, REACH, WEEE, ISO14001

• CPU: 56 physical cores, total of 112 logical cores
• Storage: BASE x 1 SSD 960GB NVMe, PLUS x 2 SSD 960GB NVMe
• 2x AC power supplies
• 128, 192 and 256 GB memory options
• Lights-Out-Management card (included in Plus package)

• 8 x 1/10GBASE-F SFP+ port card, up to 56 ports
• 4 x 10/25GBASE-F SFP28 port card, up to 30 ports
• 2 x 40/100GBASE-F QSFP28 port card, up to 14 ports

• Single Power Supply rating AC: 1300W
• Power input: 100 to 240VAC (47-63Hz)
• Power consumption 110VAC avg/max: 516W/860W
• Maximum thermal output AC: 2934.4 BTU/hr.

• Enclosure: 2RU
• Dimensions (WxDxH): 17.25 x 24 x 3.5 in. (442 x 610 x 88mm)
• Weight: 41.1 lbs. (18.8 kg)

• Safety: CB IEC 62368-1, CE LVD EN62368-1, UL62368-1, ASNZS 62368.1
• Emissions: CE, FCC IC, VCCI, ASNZS ACMA
• Environmental: ROHS, REACH, WEEE, ISO14001

• CPU: 40 physical cores, total of 80 logical cores
• Storage: BASE x 1 SSD 960GB NVMe, PLUS x 2 SSD 960GB NVMe
• 2x AC power supplies
• 96 and 128 GB memory options
• Lights-Out-Management card (included in Plus package)

• 8 x 1/10GBASE-F SFP+ port card, up to 32 ports
• 4 x 10/25GBASE-F SFP28 port card, up to 18 ports
• 2 x 40/100GBASE-F QSFP28 port card, up to 8 ports

• Single Power Supply rating AC: 850W
• Power input: 100 to 240VAC (47-63Hz)
• Power consumption 110VAC avg/max: 378W/630W
• Maximum thermal output AC: 2149.6 BTU/hr.

• Enclosure: 2RU
• Dimensions (WxDxH): 17.25 x 24 x 3.5 in. (442 x 610 x 88mm)
• Weight: 36.3 lbs. (16.5 kg)

• Safety: CB IEC 62368-1, CE LVD EN62368-1, UL62368-1, ASNZS 62368.1
• Emissions: CE, FCC IC, VCCI, ASNZS ACMA
• Environmental: ROHS, REACH, WEEE, ISO14001

• CPU: 32 physical cores, total of 64 logical cores
• Storage: BASE x 1 SSD 960GB NVMe, PLUS x 2 SSD 960GB NVMe
• 2x AC power supplies
• 96 and 128 GB memory options
• Lights-Out-Management card (included in Plus package)

8 x 1/10GBASE-F SFP+ port card, up to 32 ports
• 4 x 10/25GBASE-F SFP28 port card, up to 18 ports
• 2 x 40/100GBASE-F QSFP28 port card, up to 8 ports

• Single Power Supply rating AC: 850W, DC: 1600W
• Power input: 100 to 240VAC (47-63Hz), -36~-70VDC
• Power consumption 110VAC avg/max: 360W/600W
• Maximum thermal output AC: 2047BTU/h

• Enclosure: 2RU
• Dimensions (WxDxH): 17.25 x 24 x 3.5 in. (442 x 610 x 88mm)
• Weight: 36.3 lbs. (16.5 kg)

• Safety: CB IEC 62368-1, CE LVD EN62368-1, UL62368-1, ASNZS 62368.1
• Emissions: CE, FCC IC, VCCI, ASNZS ACMA
• Environmental: ROHS, REACH, WEEE, ISO14001

• 1x CPUs, 8 physical cores
• 1x 240 GB SSD storage
• 16 GB memory
• Virtual Systems (maximum): 10

N/A*

• Single Power Supply rating: 40W
• AC power input: 100 to 240V (50-60Hz)
• Power consumption avg/max: 30W/36W
• Maximum thermal output: 123 BTU/hr

• Enclosure: Desktop
• Dimensions (WxDxH): 8.3 x 8.3 x 1.65 in. (210 x 210 x 42mm)
• Weight: 3.1 lbs. (1.4 kg)

• Safety: UL, CB, CE, TUV GS
• Emissions: FCC, CE, VCCI, RCM/C-Tick
• Environmental: RoHS, WEEE, REACH 1, ISO14001

• 1x CPUs, 4 physical cores
• 1x 240 GB SSD storage
• 8 GB memory
• Virtual Systems (maximum): 5

N/A*

• Single Power Supply rating: 40W
• AC power input: 100 to 240V (50-60Hz)
• Power consumption avg/max: 21W/25W
• Maximum thermal output: 85 BTU/hr.

• Enclosure: Desktop
• Dimensions (WxDxH): 8.3 x 8.3 x 1.65 in. (210 x 210 x 42mm)
• Weight: 3.1 lbs. (1.4 kg)

• Safety: UL, CB, CE, TUV GS
• Emissions: FCC, CE, VCCI, RCM/C-Tick
• Environmental: RoHS, WEEE, REACH 1, ISO14001 1*
*Factory certificate
